The Trufluor+™ filter housing is designed for maximum chemical resistance and high purity for microelectronics applications. Constructed of PFA (wetted parts) and PVDF (non-wetted parts), this housing is compatible with the most aggressive chemistries. The high-purity materials of construction and cleanroom packaging insure a high level of cleanliness. The housing consists of a stationary bowl and locking ring that provides a positive seal and easy filter replacement. It is compatible with our Fluoroflow line of all-fluoropolymer cartridges including the large-diameter Fluoroflow-XL in lengths of 10, 20 and 30 inches.
Parker Trufluor +™ High Purity PFA Filter Housing Benefits:
- Excellent chemical resistance
- High-purity construction
- Packaged in cleanroom
- High flow rates
- Compatible with 2.75 and 3.25 diameter cartridges
Parker Trufluor +™ High Purity PFA Filter Housing Applications:
- Wet etch and clean (90C or less)
- Photochemicals
- DI water
Parker Trufluor +™ High Purity PFA Filter Housing Specifications:
Materials of Construction
Head and Bowl: High Purity PFA
O-Ring: FEP Encapsulated Viton
Locking Ring: PVDF (non-wetted part)
Connections:
Inlet/Outlet:
or 1 Flare
or 1 Butt-Weld
Vent/Drain:
Flare
Butt-Weld
NPTF
3/8 Closed
3/8 Flare
Maximum Operating Specifications
50 psig (3.4 bar) at 194°F (90°C)
100 psig (6.9 bar) at 77°F (25°C)
Download Parker Trufluor+ High Purity PFA Filter Housing Datasheet
Talk to one of our filtration experts today at (855) 737-4717 or fill out our online form to learn more.
The Trufluor + filter housing is designed for maximum chemical resistance and high purity for microelectronics applications.
