Highest-Flowing Cartridge for Bulk and Lower Temperature Chemical Applications
Chemflow XL
The Chemflow®-XF filter cartridge uses a superior asymmetric PTFE membrane which provides unmatched fow rates and on-stream life. It is constructed with HDPE supports providing an economical alternative to all-fluoropolymer cartridges while still maintaining a high degree of retention and cleanliness. This filter is ideally suited for bulk chemical delivery and lower temperature wet processes (<60°C). Customers using the cartridge for viscous fluids like phosphoric acid, have reported fow rates and lifetimes more than twice that of the leading competitor. These advantages help improve yields while decreasing overall filtration costs. In bulk delivery applications, the high fow allows for reduced system sizing and associated savings. It is available dry or wet-packed for quick installation.
Parker Chemflow®-XF Cartridge Benefits:
- Highest flow rates in the industry
- Long lifetime
- Wet-pack option for quick installation
- PTFE/HDPE construction for chemical resistance
- 100% integrity tested in cleanroom environment
Parker Chemflow®-XF Cartridge Applications:
- Bulk chemical delivery
- Acids, bases, solvents, photochemicals
- Wet etch and clean (< 60°C)
- Phosphoric acid
- Hydrof uoric acid
- Nitric acid
- SC1,SC2
- Solvents
Parker Chemflow®-XF Cartridge Specifications:
Materials of Construction
Membrane: PTFE (Asymmetric)
Support Layers: HDPE
Structure: HDPE
All components are thermally bonded to ensure integrity and reduce extractables.
Effective Filtration Area
SELECT:
11.0ft2 (0.99m2) per nominal 10
(250mm) cartridge
Standard:
5.7ft2 (0.51m2) per nominal 10
(250mm) cartridge
Metals Extractables*
Standard: <70ppb (total)
*In a 10% HNO3 extraction
Maximum Differential Pressure/Temperature
Forward: 55psid (4.1bar) @ 75°F (24°C)
Reverse: 30psid (2.8bar) @ 75°F (24°C)
Cleanliness (particle shedding)
Wet-packed: <1 particles/ml >0.2m after 7gal @ 1gpm
TOC/Resistivity Rinse-up (wet-packed)
TOC recovery within 5ppb of feed without additional rinse-up. Resistivity recovery within 0.2 megohm-cm of feed after 12gal @ 1gpm.
Download the Parker Chemflow XF Cartridge Datasheet
Talk to one of our filtration experts today at (855) 737-4717 or fill out our online form to learn more.
Highest-flowing cartridge for bulk and lower temperature chemical applications
